Molybdenum Wire Mesh

Tianguan Mesh specializes in producing custom compositions for commercial and research applications and for new proprietary technologies. Tianguan Mesh also casts any of the rare earth metals and most other precious materials into rod, bar, or plate form, as well as other machined shapes. We also produce Molybdenum as powder, ingot, pieces, powder, and rod. Other shapes are available by request.

Grade

M01, M02, RM01, ASTM B386, ASTM B387

Melting Point

2620 ℃

Molybdenum wire mesh is made of pure molybdenum wire or molybdenum alloy wire. Molybdenum is a type of rare metal. Due to its excellent characteristics with melting point, low elongation, good electrical and thermal conductivity. Thus, molybdenum mesh is widely used in various fields, e.g. furnace, petroleum, chemical, food, medical, machinery, and so on. The main usage is filtering, sieving, heating element and other special purposes.

Molybdenum Wire Mesh Advantage

  • High strength at high temperatures

  • Highest melting point, low density

  • Limited thermal expansion

  • Small vapor pressure

  • More ductile than tungsten

  • Anti-acid, anti-alkaline, anti-wear

  • Excellent filtering performance

  • Good electrical and thermal conductivity

Molybdenum Wire Mesh Application


  • Metallurgical

  • Machinery

  • Chemical

  • Military

  • Missile Launch

  • Aerospace

Molybdenum Mesh Properties (Theoretical)


Molecular Weight95.94
AppearanceSilvery
Melting Point2623 °C
Boiling Point4639 °C
Density10280 kg/m3
Solubility in H2ON/A
Electrical Resistivity5.2 microhm-cm @ 0 °C
Electronegativity1.9 Paulings
Heat of Fusion6.6 Cal/gm mole
Heat of Vaporization128 K-Cal/gm atom at 4612 °C
Poisson’s Ratio0.31
Specific Heat0.0599 Cal/g/K @ 25 °C
Tensile StrengthN/A
Thermal Conductivity1.38 W/cm/K @ 298.2 K
Thermal Expansion(25 °C) 4.8 µm·m-1·K-1
Vickers Hardness1530 MPa
Young’s Modulus329 GPa

Molybdenum Wire Mesh Popular Size:


Mesh
Wire Diameter
Opening
Open Area
4 x 40.025″0.225″81.0%
6 x 60.025″0.1417″72.3%
12 x 120.025″0.0583″48.9%
